Περιγραφή
Frame
Genius Alloy SL 6011
custom butted / VLK Virtual 4 Link kinematic
27.5″ (2.6 & 2.8) and 29″ (2.4 & 2.6) tire compatible with Geo-BB adj.
TBC Trunnion box construction / Boost 12x148mm
Fork
RockShox Revelation RL3 Air
custom Charger 3-Mode Damper
15x110mm Maxle Lite / 42mm offset / Tapered steerer
Lockout / Reb. Adj. / 150mm travel
Rear Shock
FOX Float EVOL Performace Trunnion
3 modes / Lockout-Trail-Descend
DPS / Reb. Adj.
Travel 150mm / 185X55mm
Remote System
SCOTT TwinLoc TSP
Suspension-Seatpost Remote
below Bar / 3 modes / integ. Grip clamp
Rear Derailleur
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Shifters
Shimano Deore SL-M6100-R / Rapidfire Plus
Crankset
Shimano FC-MT611-1
32T
Chainguide
SCOTT custom
BB-Set
Shimano BB-MT500 / shell 41x92mm
Chain
Shimano Deore CN-M6100
Cassette
Shimano Deore CS-M6100-12 / 10-51 T
Brakes
Shimano MT520 4 Piston Disc
Rotor
Shimano SM-RT64 CL / 203/F and 180/R
Handlebar
Syncros Hixon 2.0 / Alloy 6061D.B.
12mm rise / 9° / 780mm
Syncros Pro lock-on grips
H’stem
Syncros FL2.0 / 6061 Alloy
6° / integrated Top Cap / 31.8mm / 1 1/8″
Seatpost
Syncros Duncan Dropper Post 2.5
31.6mm / S size 100mm / M size 125mm / L & XL size 150mm
Seat
Syncros Tofino 2.5 Regular
Headset
Syncros Pro Press Fit E2 / Tapered 1.5″-1 1/8″
OD 50/62mm / ID 44/56mm
Hub (Front)
Shimano HB-MT410-B CL / 15x110mm
Hub (Rear)
Shimano FH-MT410-B CL / 12x148mm / Micro Spline
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
Front Tire
Maxxis Dissector / 2.6″ / 60TPI Foldable
Tubeless Ready / EXO
Rear Tire
Maxxis Rekon / 2.6″ / 60TPI Foldable
Tubeless Ready / EXO
Approx weights in KG
14.80 (with tubes)
Approx weights in LBS
32.63 (with tubes)
Max. System Weight
128 kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
