Sizes
27.5: XS,S,M,L, 29: S,M,L,XL,XXL
-
Colors
Metallic Navy
-
Frame
ALUXX-Grade Aluminum, disc
-
Fork
SR Suntour XCE, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29)
-
Shock
N/A
-
Handlebar
Giant Connect Trail, 31.8mm XS: 730mm (27.5) S: 780mm (27.5) / 780mm (29) M: 780mm (27.5) / 780mm travel (29) L: 780mm (27.5) / 780mm (29) XL: 780mm (29) XXL: 780mm (29)
-
Grips
Giant Sole-O
-
Stem
Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (27.5) / 60mm travel (29) L: 70mm (27.5) / 70mm (29) XL: 80mm (29) XXL: 90mm (29)
-
Seatpost
Giant Sport, 30.9 XS: 300mm (27.5) S: 300mm (27.5) / 375mm (29) M: 375mm (27.5) / 375mm travel (29) L: 375mm (27.5) / 375mm (29) XL: 375mm (29) XXL: 375mm (29)
-
Saddle
Giant custom
-
Pedals
MTB caged
-
Shifters
Shimano SL-M315, 2×7
-
Front Derailleur
Shimano M315
-
Rear Derailleur
Shimano Tourney
-
Brakes
TKB-172, mechanical [F]180mm, [R]160mm rotors
-
Brake Levers
RS360A, mechanical
-
Cassette
Shimano MF-TZ500, 14-28
-
Chain
KMC Z7
-
Crankset
ProWheel Forged, 22/36 XS: 165mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (27.5) / 175mm travel (29) L: 175mm (27.5) / 175mm (29) XL: 175mm (29) XXL: 175mm (29)
-
Bottom Bracket
cartridge
-
Rims
Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
-
Hubs
Giant Tracker Sport
-
Spokes
stainless, 14g
-
Tires
Kenda Booster 27.5 or 29×2.2″, wire bead
-
Extras
2.4″ max tire size
